Surpass Hobby Waterproof 3665 Sensorless Brushless Motor 3.175mm 3800KV 31500KV 2750KV 2200KV for 1/10 RC Vehicles
Description:
Item Brand:Surpass Hobby
Item Number:3665(3665/2.5T 3665/3T 3665/3.5T 3665/4.5T)
Item Name:RC car motor
Material:Metal and plastic
Color:Black
The Size of the Motor:Length 65mm diameter 36mm shaft diameter is 3.175mm length of extended shaft is 17mm
The Weight of the Motor:About 274g
Fit For:1/10 brushless rc cars
The Specification of the Motor:
KV:3800KV/3150KV/2750KV/2200KV
Watts:1400
Max Voltage:<14V/<16.8V/<18.5V/<23V
Max Amps:90A/80A/75A/60A
Rotor Poles:4
IO:4.2A/3.1A/2.6A/1.8A
Resistance:0.0042/0.007/0.0067/0.0112
Max RPM:50000
Connector:4.0mm gold
Features:
1X 3665 Brushless Motor
Item Brand:Surpass Hobby
Item Number:3665(3665/2.5T 3665/3T 3665/3.5T 3665/4.5T)
Item Name:RC car motor
Material:Metal and plastic
Color:Black
The Size of the Motor:Length 65mm diameter 36mm shaft diameter is 3.175mm length of extended shaft is 17mm
The Weight of the Motor:About 274g
Fit For:1/10 brushless rc cars
The Specification of the Motor:
KV:3800KV/3150KV/2750KV/2200KV
Watts:1400
Max Voltage:<14V/<16.8V/<18.5V/<23V
Max Amps:90A/80A/75A/60A
Rotor Poles:4
IO:4.2A/3.1A/2.6A/1.8A
Resistance:0.0042/0.007/0.0067/0.0112
Max RPM:50000
Connector:4.0mm gold
Features:
4 Pole 12 Slot Hi-torque Motor Design
CNC Machined 6061 T6 Billet Aluminum Heatsink Can
High Purity Copper Windings Maximizes Efficiency
High RPM ABEC5 Oversized Bearings
Universal fit fits all 1/10 brushless cars-multi-mounting system for M3 screws
Precision balanced rotor smoothness for best reliability and maximum RPM
Removable/Replaceable Rotor
Precision Engineered for Maximum Energy Conversion
Package included:1X 3665 Brushless Motor
Specifications
| KV | 2200KV or 3800KV or 2750KV or 3150KV |
