  3. Hubsan ACE PRO GPS 10KM 1080P FPV with 4K 30fps HDR Camera 3-axis Gimbal 3D Obstacle Sensing 35mins Flight Time RC Drone Quadcopter RTF Two Batteries
Liste de prix publique

Hubsan ACE PRO GPS 10KM 1080P FPV with 4K 30fps HDR Camera 3-axis Gimbal 3D Obstacle Sensing 35mins Flight Time RC Drone Quadcopter RTF Two Batteries

https://www.rcwarehouse.nl/web/image/product.template/6127/image_1920?unique=a2d6a01

804.99 € 804.99 EUR 804.99 €

804.99 €

  • Mode
  • Battery

This combination does not exist.

"

Hubsan ACE PRO GPS 10KM 1080P FPV with 4K 30fps HDR Camera 3-axis Gimbal 3D Obstacle Sensing 35mins Flight Time RC Drone Quadcopter RTF



Which is the Best for You?
Hubsan ACE PROHubsan ZINO MINI PRHubsan ACE SEHubsan ACE

543g

Obstacle Avoidance

1/1.3inch CMOS

CMOS f/1.85

4K@30fps+HDR

100Mbps-200Mbps Video Bitrate

35-minute Max Flight Time

SyncLeas 3 Digital Transmission

10KM Image Transmission

5000m Max Take-off Altitude

Wind Resistance Class 8

ATVT3.0 Tracking

Home VI(Visual Identity)

SC Card Inseted 8G/64G/128G avaible

Micro SD Card

Over U3 16G/32G/64G/128G

<250g

Obstacle Avoidance

1/1.3inch CMOS

CMOS f/1.85

4K@30fps+HDR

100Mbps-200Mbps Video Bitrate

40-minute Max Flight Time

SyncLeas 3 Digital Transmission

10KM Image Transmission

4000m Max Take-off Altitude

Wind Resistance Class 5

ATVT3.0 Tracking

Home VI(Visual Identity)

Night Mode

SC Card Inseted 64G/128G avaible

543g

1/2.6inch CMOS

CMOS f/2.2

4K@30fps

64Mbps-100Mbps Video Bitrate

Dedault Video Mode   1080P@60fps

Intelligent Mode 1080P@30fps

Night Mode 1080P@25fps

35-minute Max Flight Time

SyncLeas 3 Digital Transmission

10KM Image Transmission

5000m Max Take-off Altitude

Wind Resistance Class 8

ATVT3.0 Tracking

Home VI(Visual Identity)

Micro SD Card

Over U3 16G/32G/64G/128G

543g

1/1.3inch CMOS

CMOS f/1.85

4K@30fps+HDR

64Mbps-100Mbps Video Bitrate

35-minute Max Flight Time

SyncLeas 3 Digital Transmission

10KM Image Transmission

5000m Max Take-off Altitude

Wind Resistance Class 8

ATVT3.0 Tracking

Home VI(Visual Identity)

Micro SD Card

Over U3 16G/32G/64G/128G


Specifications:


Aircraft

DimensionsExpand: 182x176.5x73mm
Folded: 118.7x172.5x73mm
Diagonal Wheelbase246mm
Color
Gray
Takeoff Weight (with battery)    543g
Hover Accuracy

Indoor: Vertical +- 0.1m Horizontal +- 0.1m

Outdoor: Height<7m   Vertical < Height * 0.02m

               Horizontal < Height * 0.02m

               Height>7m Vertical +- 0.1m Horizontal +- 0.5m

Max Ascension Speed
3m/s (N) 4m/s (S) 1m/s (F)
Max Descent Speed1.5m/s (N) 3m/s (S) 1m/s (F)

Maximum Horizontal Flying Speed   (Windless at Sea Level)

12m/s (N) 16m/s (S) 1m/s (M)
Maximum Take-off Altitude         5000m
Max Wind Speed Resistance     Grade 8 Wind (16m/s)
Max Tilt Angle30deg(S) 20deg(N) 20deg(F)
PositioningGPS + GLONASS  Beidou Satellite
Flight Duration

Hovering for 33 minutes

(Windless measured in 2-4 meters hovering)                                      Slow Flight Time 35 minutes

(8m/s uniform flight)

Power System

Maximum Working Current

34A

PropellerModel: Foldable & Diameter 143mm
Color: Black
MotorOutward Rotation Brushless Motor
1503 KV2820
ESCDigital ESC Brushless 20A x 4

Camera

CMOS Image Sensor

1/1.3inch CMOS Sensor

2.4um Mixed Large Pixel

Lens Specifications

FOV 84deg

Aperture f/1.85
EFL: 6.8mm

Distortion: <1.5%

Focus Point
0.5m to
Maximum Video Encoding
4K@30fps
Shutter Speed
3-1/8000s
Video Resolution

4K: 3840 x 2160 @ 30fps

2.7K: 2720 x 1530 @ 30/60fps
FHD: 1920 x 1080 @ 30/60fps

Video Bitrate100Mbps-200Mbps
Photo FormatJPEG/RAW
Video FormatMP4 (H.265/HEVC)
Firmware UpgradeAPP Online Upgrade
Supported SD Cards

Built-in eMMC 8G/64G/128G

MicroSD Card U3 or Class10
16G/32G/64G/128G

Wireless Transmission System

Image Transmission SystemSyncLeas 3
Effective RangeFCC: 10KM
CE: <= 6KM; SRRC: <= 10KM
Band ModeFrequency Button
Transmission DelayWithin 200ms
Antenna PositionForearm Support Foot
Band ModeFrequency Button
Remote ControlHT018Y

Gimbal

GimbalHY817C
Stabilization3-Axis (tilt roll pan)
Degree of Freedom
Triaxial
Max Pitch Speed
120deg/s
Mechanical RangePitch: -120deg to 45deg
Roll: +- 35deg
Yaw: +- 35deg

Flight Controller

FC VersionThird-generation Flight Controller
Basic Flight ModeWind Resistance Mode / Sports Mode / Normal Mode / Movie Mode
Altitude Hold ModeTof Barometer
Fixed-pointVisual Optical Flow GPS
Unlock/LockOuter 'Eight' Unlock/Lock
Fill Light
Support 0.5m-5m low light environment to automatically turn on the light
One Key Take-off/LandingAPP Supported Remote Control Unsupported
Headless Mode
Out of Control Protection
Low Battery ProtectionAutomatically Return to Home and Land on Low Battery

Home Visual Recognition

(search for drone apron)

Visual TrackingThird-generation Tracking Technology (ATVT 3.0)
Waypoint Flight
Flying Around
Intelligent Battery

Power Management Overcurrent Protection                                               Over-discharge Protection  Overcharge Protection

Balanced Charging Auto-Discharging Protection

ESCSelf-developed ESC digital PWM
Motor Stall Protection
Sensing System
Forward

Binocular Visual Perception Precision Measurement Distance <12M

Fluctuate <0.5M Perception Distance >15M


Backward

Binocular Visual Perception Precision Measurement Distance <12M

Fluctuate <0.5M Perception Distance >15M


Downward

Monocular Optical Flow Tof Ranging

Effective Ranging Range 0.3-5M Fluctuate <0.1M

Remote Control

ColorGray
Wireless Transmission Solution
SyncLeas 3
Display
Highlight LED Display
Working Temperature
-5 Deg.C- 50 Deg.C
Effective Range
FCC: 10KM
CE: 6KM; SRRC: 10KM
Built-In Battery
4400mAh
Mode
Mode 2 (Left Hand Throttle)
Buzzer
Support
Support Mobile System
Android iOS
Working Time
2.5h (Normal Flight Time)
Interfaces TypeLighting / Micro USB / Type-C


Battery


Battery TypeLi-ion Battery 3S
Capacity
3800 mAh
Standard Voltage
11.1V
Charging Limit Voltage
13.05V
Discharge Rate
8C
Charging Time
90 minutes
Weight
233g
Working Temperature
-5 Deg.C- 40 Deg.C
Charging Temperature
0 Deg.C- 40 Deg.C
Smart Battery Balance
Smart Battery

Smart Charging Head

Battery Smart Buckle

Automatic Discharge
Hibernation Mode

APP

APP Name
X-Hubsan 2

Mobile Device

Requirements
iOS 10.0 or higher
Android 6.0 Or higher


Features:

- 543gm Lightweight & Foldable Design

- Front/Back/Down 3-Direction Obstacle Avoidance

- 1/1.3"" CMOS Sensor

- f/1.85 Super Large Aperture

- Ultra-Clear 4K 30-frame HDR Video

- 1080P Digital Image Transmission

- 10KM HD Video Transmission

- 3-Axis Stabilized Gimbal

- Grade 8 Wind Resistance

- ATVT3.0 Visual Active Tracking

- 3x digital ZOOM Shots

- Intelligent Battery

- Maximum Flying Time up to 35mins

- Optical Flow & GPS & TOF & Barometer


Package Included:

1 x Hubsan ACE PRO Drone
1 x Remote Controller
1 x Drone Battery
1 x Pair of Propellers
1 x Intelligent Charger
1 x Micro-USB Cable
1 x Micro-USB RC Cable
1 x USB Type-C RC Cable
1 x RC Cable for iPhones
1 x Screwdriver
1 x Manual



"

Specifications

Mode Without Storage Bag or With Storage Bag
Battery One Battery or Two Batteries
